Technical Parameters:
1.Temperature measuring range: -50 ° C ~ 99 ° C
2.Resolution: 0.1 ° C;
3.Accuracy:+- 1° C (-50 ° C ~ 70 ° C);
4.Sensor error delay: 1 minute
5.Power supply: 110-220VAC 50/60Hz, 12Vdc , 24Vdc ( Choose power supply when you place order ) ;
6.Power consumption: <3W;
7.Sensor: NTC sensor (1PC);
8.Relay contact capacity: Two Relay Cool 10A/220VAC; Heat 10A/220VAC;
9.Ambient temperature: 0 ° C ~ 60 ° C;
10.Storage temperature: -30 ° C ~ 75 ° C;
11.Relative humidity: 20% ~ 85% (No condensate)
12.Sensor length: 1.0m
13. Front Panel Size: 75×34.5mm ; Product Size: 75×34.5×85 mm ; Mounting Size: 71x29mm
Menu Instruction:
| Code |
Function |
Set Range |
Default |
| F1 |
Temperature set value |
-50.0~99.9°C |
10.0°C |
| F2 |
Difference set value |
0.3~10.0°C |
0.5°C |
| F3 |
Compressor delay time |
1~10 minutes |
3 minutes |
| F4 |
Temperature calibration value |
-10.0°C~10.0°C |
0°C |
